Unit 2: Variable and Type
Learning Objectives
After this unit, students should
- appreciate the concept of variables as an abstraction
- understand the concept of types and subtypes
- contrast between statically typed language vs. dynamically typed language
- contrast between strongly typed language vs. weakly typed language
- be familiar with Java variables and primitive types
- understand widening type conversion in the context of variable assignments and how subtyping dictates whether the type conversion is allowed.
Data Abstraction: Variable
One of the important abstractions that are provided by a programming language is the variable. Data are stored in some location in computer memory. However, we should not be referring to the memory location all the time. First, referring to something like a memory address such as 0xFA49130E
is not user-friendly; Second, the location may change. A variable is an abstraction that allows us to give a user-friendly name to a piece of data in memory. We use the variable name whenever we want to access the value in that location, and a pointer to the variable or reference to the variable whenever we wish to refer to the address of the location.
Type
As programs get more complex, the number of variables that the programmer needs to keep track of increases. These variables might be an abstraction over different types of data: some variables might refer to a number, some to a string, some to a list of numbers, etc. Not all operations are meaningful over all types of data.
To help mitigate the complexity, we can assign a type to a variable. The type communicates to the readers what data type the variable is an abstraction over, and to the compiler/interpreter what operations are valid on this variable and how the operation behaves. In lower-level programming languages like C, the type also informs the compiler how the bit representing the variable should be interpreted.
As an example of how types can affect how an operation behaves, let's consider
Python. Suppose we have two variables x
and y
, storing the values 4
and 5
respectively and we run print(x + y)
.
- If
x
andy
are both strings, the output is45
. - If
x
andy
are both integers, the output is9
. - If
x
is an integer andy
is a string (or vice versa), you would get an error.
In the last instance above, you see that assigning a type to each variable helps to keep the program meaningful, as the operation +
is not defined over an integer and a string in Python.
Java and JavaScript, however, would happily convert 4
into a string for you, and return 45
.
Dynamic vs. Static Type
Python and JavaScript are examples of dynamically typed programming languages. The same variable can hold values of different unrelated types, and checking if the right type is used is done during run time (i.e., during the execution of the program). Note that, the type is associated with the values, and the type of the variable changes depending on the value it holds. For example, we can do the following:
1 2 |
|
1 2 |
|
Java, on the other hand, is a statically typed language. We need to declare every variable we use in the program and specify its type. A variable can only hold values of the same type as the type of the variable (or its subtype, as you will see later) so we can't assign, for instance, a string to a variable of type int
. Once a variable is declared with a particular, the type of the variable cannot be changed. In other words, the variable can only hold values of that declared type.
1 2 3 |
|
The type that a variable is assigned when we declare the variable is also known as the compile-time type. During the compilation, this is the only type that the compiler is aware of. The compiler will check if the compile-time type matches when it parses the variables, expressions, values, and function calls, and throw an error if there is a type mismatch. This type-checking step helps to catch errors in the code early.
Strong Typing vs. Weak Typing
A type system of a programming language is a set of rules that governs how the types can interact with each other.
A programming language can be strongly typed or weakly typed. There are no formal definitions of "strong" vs. "weak" typing of a programming language, and there is a spectrum of "strength" between the typing discipline of a language.
Generally, a strongly typed programming language enforces strict rules in its type system, to ensure type safety, i.e., to ensure that if there are any problems with the program, it is not due to the type. For instance, catching an attempt at multiplying two strings. One way to ensure type safety is to catch type errors during compile time rather than leaving it to run time.
On the other hand, a weakly typed (or loosely typed) programming language is more permissive in terms of typing checking. C is an example of a static, weakly typed language. In C, the following is possible:
1 2 3 |
|
The last line forces the C compiler to treat the string (to be more precise, the address of the string) as an integer, through typecasting.
In contrast, if we try the following in Java:
1 2 3 |
|
we will get the following compile-time error message:
1 |
|
because the compiler enforces a stricter rule and allows typecasting only if it makes sense. More specifically, we will get a compilation error if the compiler can determine with certainty that such conversion can never happen successfully.
Type Checking with A Compiler
In addition to checking for syntax errors, the compiler can check for type compatibility according to the compile-time type, to catch possible errors as early as possible. Such type-checking is made possible with static typing. Consider the following Python program:
1 2 3 4 5 |
|
Since Python does not allow adding a string to an integer, there is a type mismatch error on Line 5. The type mismatch error is only caught when Line 5 is executed after the program is run for a long time. Since the type of the variable i
can change during run time, Python (and generally, dynamically typed languages) cannot tell if Line 5 will lead to an error until it is evaluated during run time.
In contrast, statically typed language like Java can detect type mismatch during compile time since the compile-time type of a variable is fixed. As you will see later, Java allows "addition" or string and integer, but not multiplication of a string and an integer. If we have the following code, Java can confidently produce compilation errors without even running a program:
1 2 3 4 5 6 |
|
Primitive Types in Java
We now switch our focus to Java, particularly to the types supported. There are two categories of types in Java, the primitive types and the reference types. We will first look at primitive types in this unit.
Primitive types are types that hold numeric values (integers, floating-point numbers) as well as boolean values (true
and false
).
For storing integral values, Java provides four types, byte
, short
, int
, and long
, for storing 8-bit, 16-bit, 32-bit, and 64-bit signed integers respectively. The type char
stores 16-bit unsigned integers representing UTF-16 Unicode characters.
For storing floating-point values, Java provides two types, float
and double
, for 32-bit and 64-bit floating-point numbers.
Unlike reference types, which we will see later, primitive type variables never share their value with each other, i.e., if we have:
1 2 3 |
|
i
and j
each store a copy of the value 1000
after Line 2. Changing i
on Line 3 does not change the content of j
.
Kinds | Types | Sizes (in bits) |
---|---|---|
Boolean | boolean |
1 |
Character | char |
16 |
Integral | byte |
8 |
short |
16 | |
int |
32 | |
long |
64 | |
Floating-Point | float |
32 |
double |
64 |
Long and Float Constant
By default, an integer literal (e.g., 888
) is assigned an int
type. To differentiate between a long
and an int
constant, you can use the suffix L
to denote that the value is expected to be of long
type (e.g., 888L
is a long
). This is important for large values beyond the range of int
. On the other hand, if the constant is a floating-point constant, by default it is treated as type double
. You need to add the suffix f
to indicate that the value is to be treated as a float
type.
Subtypes
An important concept that we will visit repeatedly in CS2030/S is the concept of subtypes.
Let
We use the notation
- Reflexive: For any type
, we have (i.e., is a subtype of itself). - Transitive: If
and , then . In other words, if is a subtype of and is a subtype of , then is a subtype of .
Additionally, in Java, you will find that the subtyping relationship also satisfies anti-symmetry. However, this is often omitted as it is enforced by design.
- Anti-Symmetry: If
and , then must be the same type as .
Related to the subtype relationship,
- We use the term supertype to denote the reversed relationship: if
is a subtype of , then is a supertype of . - In specific scenarios, we use the term proper subtype (or
) to denote a stricter subtyping: if and , then is a proper subtype of , denoted as .
Subtyping Between Java Primitive Types
Considering the range of values that the primitive types can take, Java defines the following subtyping relationship:
byte
<:short
<:int
<:long
<:float
<:double
char
<:int
Graphically, we can draw the subtyping relationship as an arrow from subtype to supertype. In the case of Java primitive types, we can visualise the subtyping relationship as follows:
Long
Why is long
a subtype of float
? More specifically, long
is 64-bit, and float
is only 32-bit. There are more values in long
than in float
.
The resolution lies in the range of values that can be represented with float
and long
. long
can represent every integer between -263 and 263-1, a 19-digit number. float
, however, can represent floating point numbers as big as 38 digits in the integral part (although it can not represent every floating point number and every integer values within the range).
Thus, a piece of code written to handle float
can also handle long
(since all long
values can be represented with a float
, albeit with possible loss of precision).
1 2 3 4 5 6 |
|
On the other hand, if a piece of code is written to handle long
, then giving it a float
value would be erroneous since the float
value might have more than 19 digits in the integral part and cannot be represented by long
.
1 2 3 4 5 6 |
|
Valid subtype relationship is part of what the Java compiler checks for when it compiles. Consider the following example:
1 2 3 4 |
|
Line 4 above would lead to an error:
1 |
|
but Line 3 is OK.
To understand why, let's consider the compile-type of d
and i
. The compile-time type of the variable d
is double
because that is what we declared it as. Similarly, the compile-time type of the variable i
is int
. double
can hold a larger range of values than int
, thus all values that can be represented by i
can be represented by d
(with possible loss of precision). Using the terminology that you just learned, double
is a supertype of int
.
On Line 3, the Java compiler allows the value stored inside i
to be copied to d
. The worst that could happen is that we lose a bit of precision. On Line 4, however, we try to copy the value stored in d
to i
. Since d
is a double
, it can store a value outside the range supported by i
and can have order of magnitudes difference between them. This would be a problem if the code is allowed to execute!
This example shows how subtyping applies to type checking. Java allows a variable of type
The term "widening" is easy to see for primitive types -- the subtype has a narrower range of values than the supertype. The opposite conversion is called narrowing because the size is narrower.
Some of the readers might notice that, in the example above, the value of d
is 5.0, so, we can store the value as 5
in i
, without any loss. Or, in Line 3, we already copied the value stored in i
to d
, and we are just copying it back to i
? Since the value in d
now can be represented by i
, what is wrong with copying it back? Why doesn't the compiler allow Line 4 to proceed?
The reason is that the compiler does not execute the code (which is when assigning 5.0 to d
happens) and it (largely) looks at the code, statement-by-statement. Thus, the line i = d
is considered independently from the earlier code shown in the example. In practice, Line 4 might appear thousands of lines away from earlier lines, or may even be placed in a different source file. The values stored in d
might not be known until run time (e.g., it might be an input from the user).
